Product performance description

High performance RFID integrated long range reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, Card Parking and Barrier gate control system.

Data Output Format: Wiegand 26-Bit; Mainly used for parking, elevator, logistics industry,etc
Card Type: EM-ID Card (Can't support encrypted cards, such as HID, Indala,Cobra, APCiK ,Paradox,Radio,Honeywell,etc)
30cm-100cm proximity range dependence on cards quality
The Reading range is a complex parameter,So called "Middle Range",only means the unit works with the special long range
card,that is a 2mm thickness credit size card.
Normally, the unit can also work with normal EM cards,normal 2mm/0.08" thickness card can reach 60cm/23.6" range, 0.8mm/0.03"
card can reach 40cm/15.7" range.

Specification:
Decode time: <0.2s
Communication: Wiegand 26
Card type: EM card,EM compatible card, EM4100/4102 (Can't support some encrypted cards,such as HID, Indala,Cobra, APCiK
Paradox,Radio,Honeywell,etc)
Frequency: 125kHz
Induction Distance: Common Card up to 30-40cm(11.8"-15.7") / Long range proximity card up to 80-100cm(31.5"-39.4")
Power supply: DC 12V
Data transfer range: max.80mA
Current: 200mA
Working Temperature: 0~70℃ / 32℉~158℉
Working Humidity: Less than 80%
Dimension (LxWxH): 230x230x35mm / 9.1"x9.1"x1.4"
Material: Plastic casing & epoxy saturated
